Anti Corrosion Prefabricated Steel Frame Building Construction Auto CAD Drawing Design

Place of Origin: CHINA,QINGDAO
Brand Name: YDX
Certification: CE ISO SGS
Model Number: YDX-10
Minimum Order Quantity: 10-10000 square meters
Price: $30.00-$65.00
Standard Packaging: Exported standard packing
Delivery Time: 20-30 works days
Payment Terms: T/T
Supply Ability: 10000 tons/month
Product Details
Highlight:

Anti Corrosion Prefabricated Steel Frame Building

,

Prefabricated Steel Frame Building Construction

Drawing Design: Auto CAD, Tekla...
Dimension: Customized
Package: Flat Pack Package
Grade: Q235B/Q345B
Surface Treatme: Paint Or Galvanized
Specification: Prefabricated
Corrosion Resistance: High
Primary Frame: Welded Or Hot-rolled H Beam And Column
Structure Type: Frame
Frame Type: Steel Frame
Earthquake Resistance: Strong
Windows: Aluminum
Seismic Design: High Seismic Zone
Installation Time: Short
Aesthetics: Modern
Construction Type: Frame
Cost: Moderate
Product Resistance: Corrosion Resistant
Finish: Galvanized/Painted/Cladding
Roof: Glass Wool, EPS, PU
Product Fire Resistance: Fireproof
Door: Sliding Door Or Rolling Door
Product Description
Auto CAD Drawing Design Customized Prefabricated Metal Building

A versatile and cost-effective solution for various construction projects, offering durable and reliable structures that are quick to assemble with customizable options.

Key Features
  • Product Name: Prefabricated Steel Structure Building
  • Surface Treatment: Paint or Galvanized
  • Grade: Q235B/Q345B
  • Drawing Design: Auto CAD, Tekla
  • Primary Frame: Welded or Hot-rolled H Beam and Column
  • Steel Type: High-Strength Steel
Technical Specifications
Component Specification
Main Steel Frame Steel Column & Beam: Q345B (S355JR) or Q235B(S235JR)/Welded/Hot Rolled H section steel
Supporting System Roof Purlin: C or Z Section Steel, Q235B
Wall Purlin: C or Z Section Steel, Q235B
Bracing: Steel Rod, Q235B
Roof & Wall System 1. Single Colorful Corrugated Steel Sheet (0.3-0.8mm thickness)
2. Sandwich Panel with EPS, Rock Wool, Fiberglass, PU (50-150mm thickness)
Accessories Doors: Sliding; Rolled Up Door (Manual/Auto)
Windows: Aluminum Alloy; PVC
Downspout: PVC pipe
Gutter: Galvanized Steel Sheet; Stainless Steel

Applications

Ideal for various construction needs including:

  • Industrial facilities (warehouses, factories, manufacturing plants)
  • Commercial buildings (retail stores, office spaces, shopping centers)
  • Agricultural structures (storage facilities, barns, equipment shelters)
  • Residential housing projects
Customization Options
Feature Option
Brand Name YDX
Model Number YDX-10
Certification CE, ISO, SGS
Minimum Order Quantity 1-10,000 Square Meters
Price Range $35.00-$63.00 per square meter
Delivery Time 20-30 Work Days
Packing and Shipping

All components are securely packed in flat pack packages for convenient transportation and easy handling. Includes steel frame components, wall panels, roof panels, doors, windows, screws, and bolts.

 Steel structure building assembly
FAQ
Are you a manufacturer or trading company?

We are a manufacturer and welcome visits to our facility to observe our quality control processes and production capabilities.

How competitive are your prices?

We offer the best price for equivalent quality and the best quality for equivalent prices, working to reduce your costs while ensuring product excellence.

Do you provide installation services?

We provide detailed installation drawings and can send engineers or a complete installation team upon request.

Do you accept inspection during production?

We welcome inspectors at any stage of production, including container loading.

Do you offer design services?

Yes, we provide complete design solutions using AutoCAD, PKPM, Tekla Structures and other professional software.

Project Requirements Form
Item Details
Location _____country, area
Size _____mm*_____mm*_____mm
Wind Load _____kn/m2, _____km/h, _____m/s
Snow Load _____kn/m2, _____mm
Anti-earthquake _____level
