Galvanized Sheet Space Frame Steel Structure Multi Story Metal Building Workshop
Basic Properties
Place of Origin:
CHINA,QINGDAO
Brand Name:
YDX
Certification:
CE ISO SGS
Model Number:
YDX-00
Trading Properties
Minimum Order Quantity:
10-10000 square meters
Price:
$30.00-$65.00
Payment Terms:
T/T
Supply Ability:
10000 tons/month
Product Summary
Galvanized Sheet Space Frame Steel Structure Multi Story Metal Building Workshop Product Overview The multi-story steel structure warehouse is a modern industrial building solution primarily constructed with steel as the main load-bearing component. Designed for industrial, logistics, and commercial ...
Product Details
Highlight:
Galvanized Sheet Space Frame Steel Structure
,Galvanized Metal Building Workshop
,Multi Story Metal Building Workshop
Secondary Structure：:
Purlin; Brace, Knee Brace Etc
Cladding::
PU/Rock Wool/Fiberglass/EPS
Advantage：:
Easy & Fast Install
Main Frame::
Q355 Q235
Structure Type:
Frame
Frame Type:
Steel Frame
Earthquake Resistance:
Strong
Windows:
Aluminum
Seismic Design:
High Seismic Zone
Installation Time:
Short
Aesthetics:
Modern
Construction Type:
Frame
Cost:
Moderate
Product Resistance:
Corrosion Resistant
Finish:
Galvanized/Painted/Cladding
Roof:
Glass Wool, EPS, PU
Product Fire Resistance:
Fireproof
Door:
Sliding Door Or Rolling Door
Product Description
Galvanized Sheet Space Frame Steel Structure Multi Story Metal Building Workshop
Product Overview
The multi-story steel structure warehouse is a modern industrial building solution primarily constructed with steel as the main load-bearing component. Designed for industrial, logistics, and commercial applications, it offers flexible design options, rapid construction, and excellent seismic performance.
Material Characteristics
- High Strength: Superior tensile and compressive strength for heavy load-bearing capacity
- Lightweight: Reduces foundation requirements compared to concrete structures
- Ductility: Easily shaped to meet complex architectural requirements
- Corrosion Resistance: Galvanized or painted surfaces provide long-term protection
- Fire Resistance: Requires additional fireproof coatings for high-temperature protection
Structural Features
- Modular prefabricated components for quick assembly
- Large span designs maximize interior space
- Excellent seismic performance through energy absorption
- Environmentally friendly and recyclable materials
Construction Components
| Component | Description |
|---|---|
| Primary Framing | Box beam column, cross steel column, H-shaped steel column, steel beam |
| Secondary Framing | Galvanized Z and C sections purlin |
| Roof and Wall Panels | Steel sheet and insulated sandwich panels (EPS, fiberglass wool and PU) |
| Structural Subsystem | Divider, gutter, awning, partition wall |
| Building Accessories | Sliding doors, roll up doors, aluminum windows, louvers |
Technical Specifications
| Service Life | 50-70 years |
| Place of Origin | Qingdao, Shandong, China |
| Applications | Workshop, warehouse, poultry house, garage |
| Steel Grade | Q235B, Q355B or custom |
| Connection Methods | Intensive bolt, ordinary bolt |
Custom Design Service
We provide complete customized design services. For accurate quotations and drawings, please provide:
- Building dimensions (length × width × eave height)
- Local weather conditions
- Special requirements (thermal insulation, crane needs, etc.)
Frequently Asked Questions
What kind of Industry Steel Workshop do you need?
Our experienced engineering team can design buildings to your exact specifications. We treat your building project with the same seriousness as you do.
Are you manufacturer or trade company?
We are professional manufacturers of steel structure buildings.
Do you offer guiding installation on site overseas?
Yes, we provide installation supervision and training services. Our engineers can guide assembly work on-site and provide detailed installation drawings with 24-hour online support.
What's your quality control process?
Our QC team monitors quality at all manufacturing stages. We also accept third-party inspections from agencies like SGS and BV.
Do you provide design services?
Our complete engineering team uses advanced design software (Tekla, AutoCAD, etc.) to provide economical solutions. Preliminary costing and design are provided at no extra cost.
What warranty do you offer?
Steel structures typically have a lifespan of 50-100 years depending on material quality, design standards, construction quality, and maintenance.
Project Inquiry Form
| 1. Location | _____country, area |
| 2. Size (L×W×H) | _____mm × _____mm × _____mm |
| 3. Wind load | _____kn/m², _____km/h, _____m/s |
| 4. Snow load | _____kn/m², _____mm |
| 5. Earthquake resistance | _____level |
| 6. Brick wall requirements | If yes, 1.2m high or 1.5m high |
| 7. Thermal insulation | EPS, fiberglass wool, rockwool, PU sandwich panels or metal sheets |
| 8. Door specifications | _____units, _____(width)mm × _____(height)mm |
| 9. Window specifications | _____units, _____(width)mm × _____(height)mm |
| 10. Crane requirements | If yes, _____units, max. lifting weight____tons; max. lifting height _____m |
Mr. Sun
Manager
- Email: Davidsun@ydxsteelstructure.com
- Tel: +86 18866391899
- WhatsApp: 8618866391899
-
WeChat:
18866391899
