Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse
Basic Properties
Place of Origin:
CHINA,QINGDAO
Brand Name:
YDX
Certification:
CE ISO SGS
Model Number:
YDX-DJ
Trading Properties
Minimum Order Quantity:
10-10000 square meters
Price:
$30.00-$65.00
Payment Terms:
T/T
Supply Ability:
10000 tons/month
Product Summary
Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse Our prefabricated steel frame buildings are ideal for warehouses, workshops, and industrial facilities. With a construction floor area of approximately 3200 square meters, these structures feature welded steel beams & ...
Product Details
Highlight:
Prefabricated Metal Frame Structure
,Steel Building Metal Frame Structure
,Metal Building Frame Structure
Application::
Metal Building Frame Structure Warehouse
Usage::
Steel Structure Workshop, Metal Warehouse, Factory Buildings, Garment Factory
Type::
Prefabricated Steel Frame Buildings
Surface Treatment::
Painting Or Hot-dip Galvanize
Wall And Roof::
Steel Cladding
Columns And Beam::
H Section Column&Beam
Structure Type:
Frame
Frame Type:
Steel Frame
Earthquake Resistance:
Strong
Windows:
Aluminum
Seismic Design:
High Seismic Zone
Installation Time:
Short
Aesthetics:
Modern
Construction Type:
Frame
Cost:
Moderate
Product Resistance:
Corrosion Resistant
Finish:
Galvanized/Painted/Cladding
Roof:
Glass Wool, EPS, PU
Product Fire Resistance:
Fireproof
Door:
Sliding Door Or Rolling Door
Product Description
Prefabricated Steel Frame Buildings Metal Building Frame Structure Warehouse
Our prefabricated steel frame buildings are ideal for warehouses, workshops, and industrial facilities. With a construction floor area of approximately 3200 square meters, these structures feature welded steel beams & columns, crane systems, steel cladding sheets, purlins, windows, doors, and other accessories.
Comprehensive Steel Structure Services
We specialize in both light and heavy steel structure projects, offering complete services including:
- Custom design and engineering
- Fabrication of all steel structure components
- Insulation panel production
- Professional on-site installation
Building Components
Main steel frame structure
Laying purlin
H section steel column
End wall
| Component | Specifications |
|---|---|
| Primary Framing | Box beam column, cross steel column, H-shaped steel column, steel beam |
| Secondary Framing | Galvanized Z and C sections purlin |
| Roof and Wall panels | Steel sheet and insulated sandwich panels (EPS, fiberglass wool and PU) |
| Steel Decking Floor | Galvanized steel decking board |
| Structural subsystem | Divider, gutter, awning, partition wall |
| Mezzanines, Platforms | Painted or galvanized H beam |
| Other Building Accessories | Sliding doors, roll up doors, aluminium windows, louvers, etc. |
Technical Specifications
| Service Life | 50-70 years |
| Place of Origin | Qingdao, Shandong, China |
| Application | Workshop, warehouse, poultry house, garage etc. |
| Grade | Q235B, Q355B or as per customer's need |
| Bolt Grade | M20, M16, M14 etc |
| Connection | Intensive bolt, ordinary bolt |
| Window | PVC steel or aluminum alloy |
| Downspout | PVC pipe or as per customer's request |
| Main Frame | Welded or hot rolled H-shaped steel, columns, beams, box beams and columns |
Custom Design & Quotation
- Customized designs available to meet specific requirements
- For accurate quotation and drawings, please provide:
- Building dimensions (length, width, eave height)
- Local weather conditions
Why Choose Our Steel Structures?
- Cost-effective: Professional design reduces construction time and material costs
- Eco-friendly: Specialized cladding materials provide excellent insulation; recyclable materials
- Comfortable: Spacious interiors with wide bays and elegant profiles
- Quality assurance: "Quality first, Customer first" company principle
- Proven track record: Many customers have established long-term cooperation
Packing & Loading
All structural components, panels, bolts, and accessories are packed securely for ocean transportation in 40'HQ containers. Our skilled workers use cranes and forklifts to load goods carefully at our factory loading site to prevent damage.
Project Requirements Form
| 1. Location (where will be built?) | _____country, area |
| 2. Size: length*width*height | _____mm*_____mm*_____mm |
| 3. Wind load (max. wind speed) | _____kn/m2, _____km/h, _____m/s |
| 4. Snow load (max. snow height) | _____kn/m2, _____mm |
| 5. Anti-earthquake | _____level |
| 6. Brickwall needed or not | If yes, 1.2m high or 1.5m high |
| 7. Thermal insulation | If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; if not, metal steel sheets will be used (lower cost) |
| 8. Door quantity & size | _____units, _____(width)mm*_____(height)mm |
| 9. Window quantity & size | _____units, _____(width)mm*_____(height)mm |
| 10. Crane needed or not | If yes, _____units, max. lifting weight____tons; max. lifting height _____m |
