Custom Steel Frame Building for Warehouse and Factory Construction

Place of Origin: CHINA,QINGDAO
Brand Name: YDX
Certification: CE ISO SGS
Model Number: YDX-YK
Minimum Order Quantity: 10-10000 square meters
Price: $30.00-$65.00
Standard Packaging: Exported standard packing
Delivery Time: 20-30 works days
Payment Terms: T/T
Supply Ability: 10000 tons/month
Product Details
Highlight:

custom steel frame warehouse building

,

steel frame factory construction

,

industrial steel building with warranty

Building Type: Frame
Customization: Available
Roofing: Sandwich Panel. Single Steel Sheet
Installation Method: Bolted Or Welded
Earthquake Resistance: Strong
Size: Square Metre
Shape: As The Customer Request
Product Fire Resistance: Fireproof
Windows: Aluminum
Frame Type: Steel Frame
Seismic Design: High Seismic Zone
Structure Type: Frame
Installation Time: Short
Aesthetics: Modern
Construction Type: Frame
Cost: Moderate
Product Resistance: Corrosion Resistant
Finish: Galvanized/Painted/Cladding
Roof: Glass Wool, EPS, PU
Door: Sliding Door Or Rolling Door
Product Description
Industrial Factory Building Construction Steel Structure Plant
Product Attributes
Attribute Value
Building Type Frame
Customization Available
Roofing Sandwich Panel, Single Steel Sheet
Installation Method Bolted Or Welded
Earthquake Resistance Strong
Size Square metre
Shape As The Customer Request
Product Fire Resistance Fireproof
Windows Aluminum
Frame Type Steel Frame
Seismic Design High Seismic Zone
Product Description

Our industrial steel structure warehouse combines strength, functionality, and efficiency in a durable pre-engineered solution. The robust steel framework provides excellent support and stability while maximizing storage capacity with high ceilings and open layouts.

Key Features
  • Pre-engineered design for faster construction and cost savings
  • Up to 30% lighter than conventional steel buildings
  • Fireproof and earthquake-resistant construction
  • Customizable dimensions and configurations
  • Natural lighting through large windows and skylights
  • Wide aisles and clear spans for efficient logistics
  • Low-maintenance steel construction
  • 50-70 year service life
Specifications
Main Steel Frame: Steel Column & Beam (Q345B/Q235B, Hot Dip Galvanized or Painted)
Supporting System: C/Z Section Steel Roof & Wall Purlins, Steel Rod Bracing
Roof & Wall System: Colorful Corrugated Steel Sheet (0.3-0.8mm) or Sandwich Panels (50-150mm)
Accessories: Sliding/Roll-up Doors, Aluminum/PVC Windows, PVC Downspouts, Turbine Ventilators
Applications

Workshops, warehouses, distribution centers, manufacturing facilities, hangars, agricultural buildings, and more.

Customization Options

We provide complete customized design services. For accurate quotations and drawings, please provide:

  • Building dimensions (length × width × height)
  • Local weather conditions (wind/snow loads)
  • Earthquake resistance requirements
  • Insulation preferences (EPS, fiberglass, rockwool, PU)
  • Door and window specifications
  • Crane requirements (if needed)
Steel structure packing and loading

FAQ

1. What are the main differences between a steel structure office building and a steel workshop?
Steel office buildings focus on office comfort, sound insulation, daylighting, facade aesthetics and public building fire compliance. It adopts light long-span steel frame with higher requirements for interior finishing, noise control and thermal insulation. Steel workshops are designed for heavy equipment load, crane load and mechanical vibration resistance, with heavier main steel frames and priority given to industrial operation.

2. Can the facade adopt glass curtain wall?
Sure. Glass curtain wall, aluminum veneer, stone-like coating and integrated thermal insulation wall panels are all optional facade solutions. We can customize the exterior style according to your aesthetic requirements.

3. What are the main steel materials used?
Main frame: Q355B H-section steel. Secondary components: Q235B steel. Surface treatment: sand blasting + multi-layer anti-corrosion and fire-proof paint or hot-dip galvanizing as options.

4. How many floors can the steel structure office building be built?
Conventional design: 2–6 floors. Higher floors can be customized after professional structural calculation according to local wind load, seismic standard and land conditions.


Why Choose Our Steel Structures
  • Professional design team for customized solutions
  • Skilled fabrication with advanced equipment
  • Comprehensive quality control
  • One-stop service from design to installation
  • Reliable after-sales support and maintenance
    1 Location (where will be built?) _____country, area
    2 Size: length*width*height _____mm*_____mm*_____mm
    3 wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
    4 snow load (max. snow height) _____kn/m2, _____mm
    5 anti-earthquake _____level
    6 brickwall needed or not If yes, 1.2m high or 1.5m high
    7 thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; . if not, the metal steel sheets will be ok. The cost of the latter will be much
    lower than that of the former
    8 door quantity & size _____units, _____(width)mm*_____(height)mm
    9 window quanity & size _____units, _____(width)mm*_____(height)mm
    10 crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
