Fire Retardant Prefabricated Steel Warehouse with Large Span and Easy To Assemble Design
Basic Properties
Place of Origin:
CHINA,QINGDAO
Brand Name:
YDX
Certification:
CE ISO SGS
Model Number:
YDX
Trading Properties
Minimum Order Quantity:
50-10000 square meters
Price:
$35.00-$63.00
Payment Terms:
T/T
Supply Ability:
10000 tons/month
Product Summary
Fire Retardant Steel Grade Prefabricated Steel Structure Warehouse Our prefabricated steel warehouses provide reliable storage solutions for diverse industries. Designed for maximum space utilization, durability, and flexibility, these structures feature modular components that allow for easy ...
Product Details
Highlight:
Fire Retardant Prefabricated Steel Warehouse
,Easy To Assemble Steel Structure Warehouse
,Large Span Steel Frame Building
Structural Integrity:
Excellent
Materials:
Steel
Purlin:
C Or Z Section Galvanized Steel
Product Assembly:
Easy To Assemble
Design Style:
Industrial
Wall Type:
Single/Double Steel Sheet
Product Type:
Construction Material
Product Fire Resistance:
Fireproof
Customization:
Available
Maintenance:
Low
Frame Type:
Steel Frame
Insulation:
EPS, Glass Wool,rock Woll ,PU
Apply:
Easy To Apply
Sustainability:
High
Product Description
Fire Retardant Steel Grade Prefabricated Steel Structure Warehouse
Our prefabricated steel warehouses provide reliable storage solutions for diverse industries. Designed for maximum space utilization, durability, and flexibility, these structures feature modular components that allow for easy reconfiguration and expansion.
Key Attributes
| Drawing Design | Auto CAD, PKPM, MTS, 3D3S |
| Base | Fixed upon the flat roof |
| Manufacture | Yes, in Guangzhou |
| Customization | Available |
| Durability | High |
| After Sales | 7*24h |
Structural Features
Main Frame
Constructed with high-quality Q235 or Q355 steel columns and beams in H-section form, providing exceptional strength-to-weight ratio for superior load-bearing capacity.
Secondary Frame
Includes C/Z-shape steel channel purlins, knee braces, tie rods, and braces that enhance structural integrity against wind and seismic forces.
Maintenance System
- Roof Panel Options: EPS sandwich panel, glass fiber sandwich panel, rock wool sandwich panel, PU sandwich panel, or steel sheet - offering varying levels of insulation and fire resistance
- Wall Panel Options: Sandwich panels or corrugated steel sheets that provide weather protection and temperature regulation
Technical Specifications
| After-sale Service | Online technical support, Onsite Installation, Onsite Training, Onsite Inspection |
| Project Solution Capability | Graphic design, 3D model design, total solution for projects |
| Application | Warehouse |
| Material | Q235/Q345 Steel |
| Place of Origin | Shandong, China |
| Warranty | 2 years |
| Brand Name | Tsin |
| Model Number | 94069000 |
| Roof cladding | Steel Sheet + Sandwich Panel |
| Main structure | Portal Frame Steel Structure |
| Surface treatment | 1. Painting 2. Galvanized |
Product Advantages
Wide Span: Single span or Multi-span designs available
Cost Effective: Unit price range from USD50/m² to USD80/m² according to client requirements
Long Lifespan: Approximately 20-50 years of service life
Fast Construction: Quick assembly and easy installation process
Additional Benefits: Environmental protection, stable structure, earthquake resistance, water proofing, and energy conservation
Detailed Specifications
| Product Name | Steel Structure Warehouse Building Construction Large Span Easy Assemble |
| H Beam Dimensions | 400-1500mm |
| Thickness | Web plate: 6-32mm, Wing plate: 6-40mm |
| Height | 200-1200mm |
| Color | Customized according to customer requirements |
Main Components
| Base | Cement and steel foundation bolts |
| Main Frame | H beam construction |
| Material | Q235B, Q355B or others as customer's request |
| Purlin | C or Z purlin, size from C120-C320, Z100-Z200 |
| Bracing | X-type or other type bracing made from angle, round pipe |
| Bolt | Plain bolt and high strength bolt |
| Roof & Wall | Sandwich panel and color plate |
| Door | Sliding or rolling door |
| Window | Aluminium alloy window |
| Surface Treatment | Two ways of anti-rust painting or hot dip galvanized |
Installation Methods
Method 1: We provide shop drawing before installation.
Method 2: If you still don't know how to install, we will teach you the installation in our factory. When necessary, we will assemble a sample steel structure building for you.
Packing & Loading
All the structure components, panels, bolts and accessories will be well packed with standard package suitable for ocean transportation and loaded into 40'HQ containers. All products are loaded at our factory using crane and forklift by skilled workers to prevent damage during transportation.
Why Choose Our Steel Structures?
- Professional Design Team: We design drawings according to your requirements or calculate steel quantity based on your drawings
- Skilled Fabrication: Advanced equipment and independent production schedules for each project
- One-Stop Service: Complete integrated proposals for your projects based on extensive experience
- Quality Assurance: Professional QC team ensures products and services meet your specifications
- Comprehensive After-Sales: Full support for maintenance of insulation and steel components throughout product lifecycle
Project Requirements Form
| 1. Location (where will be built?) | _____country, area |
| 2. Size: length*width*height | _____mm*_____mm*_____mm |
| 3. Wind Load (max. wind speed) | _____kn/m², _____km/h, _____m/s |
| 4. Snow Load (max. snow height) | _____kn/m², _____mm |
| 5. Anti-Earthquake | _____level |
| 6. Brickwall Needed or Not | If yes, 1.2m high or 1.5m high |
| 7. Thermal Insulation | If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; if not, metal steel sheets will be suitable at lower cost |
| 8. Door Quantity & Size | _____units, _____(width)mm*_____(height)mm |
| 9. Window Quantity & Size | _____units, _____(width)mm*_____(height)mm |
| 10. Crane Needed or Not | If yes, _____units, max. lifting weight____tons; max. lifting height _____m |
